Step Quadro Fixed Recessed

Step Quadro Fixed Recessed Wall Light Textured Grey

Recessed linear steplight for outdoor installation in the wall, phospho-chromatised and polyester powder coated die-cast copper-free aluminium body and frame, tempered frosted glass diffuser, polypropilene housing for recess, moulded silicone gasket and stainless steel screws. Built-in LED driver 220-240V 50-60Hz, with 24 low-power SMD3528 LED. IP65 rating.

Inputs

Outputs

System Lumen
60lm
System Efficacy
60lm/W
CRI
CRI80
Voltage
240V
LED Module
CREE
LED Driver
Integral
Installation Method
Fixed Recessed
Lifetime
50000hrs
Dimensions
79mmx79mmx77mm
IP Rating
IP65
Warranty
5 Years
Add-Ons
IK07 Rated
Cutout Size
Ø71mmx77mm
Download Datasheet
Item code AWL43FR23.830CRA.01W0201
